Transformers — /transformers

A Transformer converts the payload between the sender’s format and the receiver’s: JSON ↔ XML, renaming fields, flattening structures, computing derived values, splitting one message into several.

The same Transformer is reusable in Delivery Definitions, in Collections and in the forwardings of a Collection to several interfaces.

Where the Transformer sits in the flow

• Delivery — between receipt and sending to the destination.
• Collection — between reading the source and forwarding to the target interfaces.
• Forwarding — a Transformer of its own per destination, when the same collection feeds systems that expect different formats.
• Producer Application — on a Delivery that receives from several systems, a Transformer of its own per producer, which converts that producer’s format into the Delivery’s and runs before the Delivery Transformer. See Transformer by producer Application.

Who uses this Transformer

The Definitions using column shows, on each row of the listing, one chip per use, in the form Application icon · Application code — Collection/Delivery icon · Definition code. The chip colour matches the rest of the system: teal for Collection, blue for Delivery.

The chip distinguishes the two natures of the link:

The distinction matters when changing something: touching a forwarding Transformer affects one branch of the Collection, not the whole Collection. The forwarding row shows the destination after an arrow; the By producer row shows the producer’s code next to a send icon — without it, the chip would look the same as the Delivery’s direct use. The usage modal’s search also finds it by the producer’s code.

Reference comes in grey, with a link icon, outside the teal/blue pair that across the product means Collection and Delivery in operation. A Definition that is in the Scope and using it counts once, as real usage. See Scope is not usage.

When there are more uses than fit in the column, the +N chip opens the same list, and the usage modal has a search field of its own — a shared Transformer accumulates dozens of rows, and scrolling in search of the right one is not checking anything.

Deleting a Transformer in use

Deleting a Transformer that a Delivery, a Collection or a producer Application still uses is refused, with a message saying how many uses remain — remove it from there first. Before, the same situation reached the screen as a generic server error.

A forwarding does not block the deletion: the destination that used the deleted Transformer falls back to the destination Delivery’s Transformer, as it already did.

Writing by hand — /transformers/:id

A Monaco editor (the same as VS Code), with an immediate test against a sample payload. Use new as :id to create one from scratch.

The script is JavaScript. Besides the payload, it receives a context:

The Result in full screen

The 3. Result column is narrow for a large result. The full-screen icon, next to the copy one, opens the result in a popup with:

• Original / Formatted — JSON or XML indented for reading. A result that is not valid JSON or XML stays in Original only.
• Copy original or Copy formatted — copies what is on screen, and the label says which.

Formatting is for reading only: Transformation OK and the Expected Output use the original result, exactly as the script produced it.

Converting XML

Three functions are available in the script, with no import:

Both functions drop the namespace prefix and keep attributes. xmlToJson still exists and is still the default on purpose: every Transformer already written was written against its behaviour, and a script comparing if (x.Qtd > 10) would start comparing text if the conversion changed underneath — the break would show up on the first message, in production.

The name opens locked

When editing, the Transformer field comes with a padlock. The name is not just a label: it is the natural key for import and export (packs, export files, MCP tools) and it is how the team recognises the script in the Definitions using it. Renaming makes an older pack create a new Transformer instead of updating this one.

Clicking the padlock brings up the impact warning; only after confirming does the field unlock. There is no padlock when creating — nothing points at the name yet. The change is recorded in the audit log, under its own action Change Transformer Name.

Scope is not use

The target button, next to the scope tag, opens the list of Application / Interface / Definition this Transformer reaches. That list is a reference, not a link: the actual link is created by the Definition itself, on its own screen.

To leave no doubt, every row in the popup carries an Actual use column:

An In use reference cannot be removed from here: undo the link on the Definition screen first — on those rows the bin icon is dimmed, with the reason in the tooltip.

Removing takes two steps, just like adding. The bin marks the reference to leave — the row is highlighted and the icon turns into an undo —, and nothing is removed until you click Save. Closing the window discards the marks, both the removals and any add rows you filled in.

Version history

Every saved change to the script, the payload models or the name creates a version. In the history:

• the newest is the Current one — the snapshot of what is saved today;
• the rest are Obsolete: kept for review and for restoring, but not what runs.

Restore this version asks for confirmation and only changes what is on screen — the script and the models become those of the chosen version, but nothing is written until you click Save Transformer. To back out, leave the screen without saving.

An obsolete version can be removed, also with confirmation; removal is permanent and goes to the audit log. The Current version never leaves — without it the history would lose the reference to what is live.

Moving a Transformer to another environment

A Transformer written and tested in staging can go to production — or to another customer’s installation — as a file. There is no need to go through Import/Export in the Danger Zone, which moves whole domains at once.

Exporting

In the listing, the Export to file icon on the Transformer’s row downloads a .json with the record, the script, the input and output payload models and the list of Scope Definitions.

Deliberately left out: the version history (the destination starts counting from scratch) and the authorship from the source (whoever imports becomes the author). If you only see part of the Scope, the file carries only that part.

Importing

The Import button, next to New Transformer, asks for the file and shows what will happen before writing anything.

For each Scope Definition, the CMS looks for the same trio of short names here and reports what it found:

And for each row you choose:

• Use this one — only shown when the trio matched; reuses the Definition that was found;
• Choose another — opens the Application → Interface → Definition combos of this environment, so you can point that Scope by hand;
• Skip — discards the row.

Skipping every row (or importing a Transformer that was already global) brings the Transformer in as Global: it becomes available to every Definition, and the link can be made later, on each Definition’s screen.

Choose another depends on the /applications and /interfaces Tools: without them the combos would be empty, and the screen shows the option disabled with the reason. The chosen Definition is also re-checked on the server against your Interfaces — you cannot tie the script to an area you cannot reach.

Every import is recorded in the audit log, under the Import Transformer action, with the name that came in the file, the name it was created with and how many Scope links were born.

Generating with AI

Someone who does not write code can generate the script by describing the result. It is one of the ways the CMS uses AI — see Configuration assistants for the full set.

The provider (Anthropic, OpenAI or one compatible with the OpenAI API, such as Ollama, Groq or OpenRouter) is chosen in Settings → AI. The API key is stored encrypted and never shown again.

Connecting two Definitions that already exist

The Integrate two Definitions button at the top of this screen opens the assistant that generates the Transformer between two ends already configured in the CMS, from what actually flows through each one. See Between Applications.

The execution engine

Implemented in cms-api/src/modules/transformador/.

Isolation

Scripts run in worker_threads, in a pool managed by TransformadorWorkerPool:

• the API’s main thread is never blocked by a slow or hung script;
• each worker has a memory limit via resourceLimits;
• besides the vm timeout inside the worker, there is an external timeout: a hung worker is killed and replaced in the pool.

The pool size comes from TRANSFORMADOR_WORKER_POOL_SIZE (default 4).

Generation is decoupled from execution

The AI lives in modules/transformador-ia/, separate from the pool. Every generation is recorded in TransformadorGeracao with the prompt used and can be restored.

Versions and scope

• TransformadorVersao — script version history.
• TransformadorEscopo — where the transformer is in use.

The consolidated usage in the listing does not come from TransformadorEscopo: it is counted across the five real link tables (Delivery, Collection, the two forwarding kinds and DefinicaoTransformadorProdutor, the Transformer by producer Application). TransformadorEscopo only holds the reference list behind the scope popup — the difference between the two is exactly the Actual use column.
