SAP RFC / BAPI

The synchronous path: the CMS calls SAP. A Collection calls a function and turns the return into a message; a Delivery turns the message into the parameters of a call. See SAP for the overview of all three paths.

Architecture

The RFC integration does not run inside cms-api. It lives in the cms-sap-connector microservice, which isolates the SAP NetWeaver RFC SDK (native C code, via node-rfc) from the main process.

The reason: a native addon crash would take down the API, the scheduler and the workers with it. In a separate process, it only takes down the SAP integration.

The service stays on the internal docker-compose network only (cms-network), with no published port and without going through nginx. Endpoints except /health require the X-Internal-Token header when SAP_CONNECTOR_TOKEN is set.

Installing the SDK

Communication uses the official SAP NetWeaver RFC SDK, the same library used by production RFC integrations. There is no emulation and no intermediate translation: the call leaves the connector straight for your SAP’s RFC gateway, with the same protocol as a remote ABAP program.

The SDK is licensed by SAP and cannot be redistributed, so it does not ship inside the image.

Configuring the connection

On the SAP-type External Connection, the RFC client block accepts two connection modes:

Plus: client, user, password, language, SAProuter (optional), connection pool size and the function used in the test (RFC_PING by default).

The Timeout (ms) field, next to the test function, is the time limit for Test Connection and for Keep Alive: blank means 10000, and it accepts 1000 to 60000. It is for the SAP that answers slowly — through SAProuter, VPN or from another continent — and that, with the fixed limit from before, stayed OFF while it was actually up. For metadata lookups (describing the function or the structure, searching for the BAPI) the field only raises their default limit, never lowers it. Collection and Delivery calls do not use this field: each has its own timeout.

The Test Connection button makes a real call and returns SAP’s error when it fails — where the deployment classics show up: locked user, wrong client, unreachable SAProuter.

Collection — SAP_RFC

Calls a function module or BAPI and turns the return into a message.

Finding the function

The search button looks up functions in SAP by name or fragment and shows each one’s description. On selection, the CMS imports the signature: IMPORT and EXPORT parameters, and the tables.

Declaring the parameters

Parameters are declared in JSON, but you edit them by clicking the fields in the SAP Function Parameters popup. Each IMPORT parameter has an origin:

Structures. A structure parameter opens in its own editor (Monaco, in JSON), with the variables panel beside it: the Collection/Delivery Input Variables and the Globals. You can create a new Input Variable straight from the panel and use it in the structure right away — {"SHORT_TEXT": "{{descricao}}", "EQUIPMENT": "{{equipamento}}"}.

Free Input Variables. Besides the ones born from a “comes from outside” parameter, you can declare variables that only show up inside structures or follow-up calls. They join the contract the same way.

In TABLES parameters, out lists the output tables to return, and in (optional) maps the input tables — origin fixo (a literal array of rows) or jsonpath.

{
  "in":  { "PLANTSELECTION": { "origem": "fixo",
           "valor": "[{\"SIGN\":\"I\",\"OPTION\":\"EQ\",\"PLANT_LOW\":\"1000\"}]" } },
  "out": ["RETURN", "T_MATERIAIS"]
}

Scheduled or on-demand Collection

Here is a design decision that changes the behaviour of the whole integration:

• no Input Variables — the Collection is swept by the scheduler, on the configured cron;
• at least one Input Variable — the Collection leaves the scheduler and gets a URL of its own, executed on demand by whoever calls it.

In on-demand mode, if a required variable is missing, the API rejects with HTTP 400 right away — it does not become a message in error. See Public API.

Testing without leaving the CMS

The test button runs the function with the declared parameters and shows the return. That is what avoids the “save, wait for the cron, look at the message in error, fix” cycle.

For large tables there is also the table fields popup, which lists the return’s columns and lets you peek at values — useful to find the exact field name before writing the Transformer.

Metadata cache

The function’s metadata (import/export parameters and tables) is kept in a local cache in the database. The parameters popup works offline, and an “Update from SAP” button reloads it when the function changes in the ERP.

Delivery — SAP_RFC_CALL

The reverse path: the message’s data becomes the parameters of an RFC/BAPI call.

The configuration is the same — function, IMPORT parameters, TABLES parameters — with two important differences.

Input Payload

The fields marked “comes from outside” form the Input Payload: the contract the delivered message must fulfil. Each alias resolves against the message payload, and marking one required makes the CMS refuse the send, with a clear message, when the field is missing.

Commit

Write BAPIs record nothing until the commit. The “Call BAPI_TRANSACTION_COMMIT after the call” option makes the connector issue it in the same RFC session as the call — and as the follow-up calls, after the last one. If the RETURN of any step comes back with type E or A, the connector issues BAPI_TRANSACTION_ROLLBACK instead of the commit.

Call next, in the same session

Some BAPIs only work in pairs: BAPI_ALM_NOTIF_CREATE builds the PM notification in the session’s memory, and only BAPI_ALM_NOTIF_SAVE saves it — in the same session. Each CMS message opens its own RFC connection, so two chained Deliveries (or a forwarded response) will not do: the notification created in the first does not exist in the second.

The “Call next, in the same session” section adds steps to the same Delivery (and to the Collection), run one after another on the main function’s connection:

• each step has its own function (with the same SAP search), its own import parameters and output tables;
• the resposta origin reads a field from the previous step — NOTIFHEADER_EXPORT.NOTIF_NO, for example. The screen lists the previous step’s output fields and suggests the one with the same name;
• input payload fields and structures work as in the main function;
• each step’s return goes into the result under the function name (BAPI_ALM_NOTIF_SAVE.NOTIFHEADER.NOTIF_NO).

The step editor fills itself from SAP: once you pick the function, the import parameters show up ready to map, and the output tables are chosen in a popup.

Errors

SAP’s error reaches the CMS with the original text, in the connection’s language. From there:

• a communication failure (gateway down, locked user) becomes a Delivery Error, with retries;
• a business return (the RETURN table with type E) becomes a Business Error when a rule is registered — and that is how “order not released” stops looking like success.

The SAP Packs already ship those rules for the scenarios they cover.
